Superstrut CPC050 Pipe Straps, Pipe Clamps & Hangers (Series 700)
Superstrut CPC050 Pipe Straps, Pipe Clamps & Hangers (Series 700)
- MPN: CPC050
- UPC: 616013106983
- PPN: T-B-CPC050
Available to Order
Company Stock:
0
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To view product inventory
CAD$2.80/ EA
Description
Clamp, One-Piece Cable and Pipe, EMT and Rigid Conduit Trade Size 1/2 Inch, Cable Outer Diameter Range .650-.890 Inches, Steel
Features
- Heavy-duty 5/16 Inch hex bolt with multi-driver head, Robertson square, Phillips cross-recess and slot, provides a full range of installation options.
- Reconfigure wiring without complete disassembly. Remove cables easily without disturbing neighboring clamps.
- Parallel hook design keeps conduits and cable square with strut.
- Works with all depths of strut - 13/16 Inch to 3 1/4 Inch
Specifications
North American Specifications (UNSPSC)
- UNSPSC
- 31162906 Hose or pipe clamps
- Brand Name
- Superstrut
- Special Features
- One-piece, heavy-duty construction ready to install right out of the box, no need to break apart and reassemble, no screws or bolts to drop.
- Standard
- UL E160899
- Size
- 1/2 Inch
- Width
- 1 in
- Minimum Clamp Diameter
- 0.650 Inches
- Thickness
- 0.112 Inches
IGCC3064 Hose or pipe clamps
TypePipe Straps, Pipe Clamps & Hangers (Series 700)
ApplicationAttaches a full range of EMT, Rigid conduit and cable to strut channels.
MaterialSteel
FinishGoldGalv/Standard
Maximum Clamp Diameter0.890 Inches
Number Of Holes1
European Specifications (ETIM)
- ETIM
- EC002470 Mounting clamp for cable protection tubes
- Rotatable
- N
MaterialSteel
Packaging
- Outer Quantity
- 100
- Weight Uom
- 9.88 lbs. per 100
Outer Dimensions (inches)10x5.75x7.5
