Killark ZS209CR 3/4 Inch Nylon Cord Connector, Cord Range .500-.625 Inch, Brown
Killark ZS209CR 3/4 Inch Nylon Cord Connector, Cord Range .500-.625 Inch, Brown
- MPN: ZS209CR
- UPC: 783936989709
- PPN: HBL-ZS209CR
- UNSPSC: 39121431
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$18.55/ EA
Description
3/4"Nylon Cord Connector, Cord Range .500-.625, Brown
Features
- Nylon retention ring for increased holding power
- Neoprene bushing seals against moisture
- Nylon connectors obtain approximately the same retention values as metal cord connectors
- Nylon retention ring for increased holding power. Neoprene bushing seals against moisture. Nylon connectors obtain approximately the same cord retention values with hand tightening that can be produced only by wrench tightening of metal cord connectors.
Specifications
Certifications
- EU RoHS Indicator
- Contact Manufacturer
Specifications
- Country of Origin
- China
- Height
- 2 in
- Length
- 2 in
- Color
- Gray
- Special Features
- Nylon retention ring for increased holding power. Neoprene bushing seals against moisture. Nylon connectors obtain approximately the same cord retention values with hand tightening that can be produced only by wrench tightening of metal cord connectors.
- Width
- 1 in
- Power Factor
- 0.9
- Class Code
- D30
- Freight Class Code
- 06168002
- Image Actual Or Representative
- R
- MSDS Flag
- No
- Returnable Indicator
- Yes
- Cable Range
- .500 - .625 in
- CSA File Number
- LR73478
- UL File Number
- E22698
- Material
- Nylon
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 2.500 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 25 EA
Dimensions2 in x 1 in x 2 in
Hub Size3/4"
ApplicationDurable nylon construction makes these connectors perfectly suited to corrosive environments. Typical applications for nylon cord connectors include food processing facilities, chemical and sewage treatment plants, and off-shore and dockside installations
Size2 in x 1 in x 2 in
TypeStraight Cord Connector
Frequency Rating60 Hz
ARRA CompliantContact Manufacturer
Description - InvoiceCONN STR 3/4" .500-.625 NM
Harmonization Code3926909989
Lead Time20 wk
Order Multiple1 EA
Sub Class CodeD30D234
Cord Range.500-.625,
Gross Weight with Packaging0.1
Color CodeBrown
SeriesZ Series
BOX SIZE5.000x8.250x5.500 (in)
Carton - Number of Sub Packs25
Carton - SCC-14 Next Lower Level Sub Pack00783936989709
Master Pack DescriptionEach
