ABB 1SVR740020R3300 Multifunction Time Relay 0.05s-300h, 24-48VDC/24-240VAC, 2 c/o
ABB 1SVR740020R3300 Multifunction Time Relay 0.05s-300h, 24-48VDC/24-240VAC, 2 c/o
- MPN: 1SVR740020R3300
- UPC: 804325584388
- PPN: ABB-1SVR740020R3300
- UNSPSC: 39122329
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$309.14/ EA
Description
The CT-MVS.22P is a multifunction electronic time relay from the CT-S timer range. It provides 10 timing functions with 10 time ranges from 0.05 s to 300 h. This time relay operates with a rated control supply voltage of 24 - 48 V DC / 24 - 240 V AC and has a 2 c/o (SPDT) output with contacts rated at 250 V / 4 A. A control input works with voltage-related (non-floating) triggering. A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers maintenance free Easy Connect Technology with push-in terminals.
Specifications
- Contact Configuration
- 2 c/o (SPDT) contacts
- Contact Rating
- 250 V, 4 A
- Timer Relay Type
- Impulse OFF, Impulse ON, OFF-Delay, ON-Delay, Star-Delta
- Electrical Durability
- AC-12 100,000 cycles
- Rated Operational Current DC-13 (Ie)
- (24 V) 2 A
- Rated Operational Current AC-15 (Ie)
- (230 V) 3 A
- Rated Insulation Voltage (Ui)
- Input Circuit / Output Circuit 500 V, Output Circuit 1 / Output Circuit 2 300 V
- Rated Control Supply Voltage (Us)
- 24 ... 240 V AC, 24 ... 48 V DC
- Minimum Switching Capacity
- 12 V, 10 mA
- Pilot Duty UL/CSA
- B300
- Maximum Operating Voltage UL/CSA
- Output Circuit 300 V AC
- Degree of Protection
- Housing IP50, Terminals IP20
- Mounting on DIN Rail
- TH35-7.5 (35 x 7.5 mm), TH35-15 (35 x 15 mm) acc. to IEC 60715
- Terminal Type
- Screwless Terminals
- Connecting Capacity UL/CSA
- Flexible 2x 18-16 AWG, Rigid 2x 20-16 AWG
- Product Net Width
- 22.5 mm
- Product Net Depth / Length
- 103.7 mm
- Ambient Air Temperature
- Operation -25 ... +60 °C, Storage -40 ... +85 °C
- RoHS Status
- Following EU Directive 2011/65/EU
- Flammability According to UL94
- V-0
- E-Number (Sweden)
- 4033129
- Maximum Operating Altitude Permissible
- 2000 m without derating
Control Supply Voltage24 ... 240 V AC, 24 ... 48 V DC
Time Range0.05 s ... 300 h
Mechanical Durability30,000,000 cycles
Rated Operational Current DC-12 (Ie)(24 V) 4 A
Rated Operational Current AC-12 (Ie)(230 V) 4 A
Rated Operational VoltageAuxiliary Circuit 250 V
Rated Impulse Withstand Voltage (Uimp)Input Circuit 4 kV, Output Circuit 1 / Output Circuit 2 4 kV
Short-Circuit Protective DevicesOutput Circuit NC - F Type Fuses 6 A, Output Circuit NO - F Type Fuses 10 A
Rated Frequency (f)DC, 50 Hz, 60 Hz
Contact Rating UL/CSAB300
Overvoltage CategoryIII
MaterialNot specified
Mounting Position1 ... 6
Connecting CapacityFlexible with Ferrule 2x 0.5 ... 1.5 mm², Flexible with Insulated Ferrule 2x 0.5 ... 1.5 mm², Flexible 2x 0.5 ... 1.5 mm², Rigid 2x 0.5 ... 1.5 mm²
Wire Stripping Length8 mm
Product Net Height85.6 mm
Product Net Weight0.131 kg
Pollution Degree3
StandardsCAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61812-1, UL 508
E-Number (Finland)2712217
Customs Tariff Number85364900
