Schneider Electric QO816L100F QO Load Centre 240V 100A 1 Phase 8 Spaces NEMA 1
Schneider Electric QO816L100F QO Load Centre 240V 100A 1 Phase 8 Spaces NEMA 1
- MPN: QO816L100F
- UPC: 785901785675
- PPN: SCH-QO816L100F
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
CAD$181.57/ EA
Description
QO® Circuit Breaker Loadcentres, QO816L100F, from Square D® are Underwriters Laboratories (UL) Listed and CSA certified panelboards. They are designed to meet residential, commercial, and industrial requirements to protect electrical systems, equipment, and people. They are available in both traditional and plug on neutral configurations. There is 3 types of mains available. There is main circuit breaker, main lugs, and generator panel. Single and three phase options are available. The bus bars are tin plated copper and are shielded. Indoor and outdoors enclosures are an option. QO Load Centers enable the use of a full complement of accessories. This 1 phase load center has 8 spaces and 16 circuits. This system provides 100A fixed main lugs in a NEMA 1 enclosure. It also includes a flush cover, and is UL rated.
Specifications
- Voltage
- 120/240 V AC
- Short-Circuit Current
- 10 kA
- Wiring Configuration
- 3-wire
- Number of Spaces
- 8
- Loadcentre Type
- Fixed Mains (lugs)
- Width
- 226 mm
- Surface Finish
- baked enamel gray
- Certification
- UL Listed
- Country of Origin
- Mexico
Amperage100 A
Phases1 phase
Tightening Torque50 lb.in for main lugs, AWG 8...AWG 1 aluminum/copper
Number of Circuits16
Height319 mm
Materialtin plated aluminum busbar, welded sheet steel enclosure
Enclosure TypeNEMA 1 indoor, flush cover
RoHS ComplianceCompliant with Exemptions
